OC-1650UV
| DESCRIPTION | UNIT | OC-1650UV | |||
| INJECTION UNIIT | A | B | C | D | |
| Shot volume | cm3 | 7043 | 8266 | 9586 | 11006 |
| Shot weight | g | 6408 | 7520 | 8723 | 10015 |
| (PS) | Oz | 226 | 265 | 307 | 353 |
| Screw diameter | mm | 120 | 130 | 140 | 150 |
| Injection pressure | Mpa | 193 | 164 | 142 | 123 |
| Screw L/D ratio | L/D | 26:1 | 24:1 | 22:1 | 20:1 |
| Screw stroke | mm | 620 | |||
| Screw speed | r/min | 0-100 | |||
| CLAMPING UNIT | |||||
| Clamping force | KN | 16500 | |||
| Opening stroke | mm | 1520 | |||
| Planten size | mm | 2230x2080 | |||
| Space between tie bars | mm | 1500x1350 | |||
| Mold thickness(Min-Max) | mm | 700-1500 | |||
| Max.daylight | mm | 3020 | |||
| Ejection stroke | mm | 350 | |||
| Ejection force | KN | 318 | |||
| POWER UNIT | |||||
| Hydraulic system pressure | Mpa | 16 | |||
| Pump motor(v) | KW | 3x45 | |||
| Pump motor (s) | KW | 3x67 | |||
| Heating capacity | KW | 92 | |||
| Number of temp control zones |
KW | 7+nozzle | |||
| GENERAL | |||||
| Dry-cycle time | Sec | 14 | |||
| Oil tank capacity | L | 2900 | |||
| Machine dimensions | m | 15.3x3.1x4.1 | |||
| Machine weight | Kg | 112000 | |||
